Molecular™ Electroplating and Coating Industry Pure Water
System
At a glance
In electroplating and coating industry, in order to enhance the parts smooth finish, brightness and adhesion, the plating solution requires pure water with conductivity below 15 us/cm- 5 us/cm, and the rinsing of the plate requires below 10 us/cm. Besides, ultrafiltration and reverse osmosis technology can also be used to recycle precious metal ions in the rinsing water, while the outlet water can be used for cleaning again.
Electroplating full-closed production line and zero discharge water treatment system
● Water purification system in the preparation of plating solution
● Recycling of rare metals in the electroplating rinsing water
●Rinsing water recycling system with zero discharge
Typical technology
Tap water→ Water pump→ Multi-media filter→ AC filter→ Automatic dosing device→ Security filter→ High
pressure pump→ 1st stage RO→ Intermediate water tank→ High pressure pump→ 2nd stage RO→ Pure water
tank→ Pure water pump
Rinsing water→ Water tank→ Water pump→ Multi-media filter→ Security filter→ Ultrafiltration→ Plating solution
recycling tank→ High pressure pump→ RO→ Cleaning water tank
